MIL-PRF-15733/34R
Salt atmosphere (corrosion): In accordance with MIL-PRF-15733 and method 101, MIL-STD-202; test condition A.
Shock (specified pulse): In accordance with MIL-PRF-15733 and method 213, MIL-STD-202; test condition I.
Vibration, high frequency: In accordance with MIL-PRF-15733 and method 204, MIL-STD-202; test condition D (20 G).
Moisture resistance: In accordance with MIL-PRF-15733 except that after the 24-hour drying period the measured
insulation resistance shall meet the initial requirements.
Life: In accordance with MIL-PRF-15733 and method 108, MIL-STD-202, test condition D (1,000 hours) for
qualification inspection; test condition B (250 hours) for group C inspection.
VERIFICATION
Qualification inspection:
Transient voltage test shall be included in MIL-PRF-15733 qualification inspection group I following the overload
test.
Conformance inspection: Conformance inspection shall be as specified in MIL-PRF-15733. The following
exceptions shall apply:
a.
Prior to group A inspection, 100 percent of the lot shall be subjected to voltage conditioning and
radiographic inspection. Failures shall be removed from the lot. If total rejects from the voltage
conditioning test exceed 10 percent , the entire lot shall be rejected.
b Group C inspection shall include the voltage transient test as specified in table II of this specification sheet.
TABLE II. Group C inspection 1/
Inspection
Number of samples
Number of
to be inspected
defectives allowed
Subgroup 6
Transient voltage
4
0
1/ This table is in addition to the group C inspection table shown in
Extension of qualification:
Qualification testing and approval for M15733/34-0005, -0006, and -0001 shall be sufficient to grant qualification
approval to M15733/34-0029, -0006, -0016, -0020, -0021, -0030, -0004, -0005, -0001, and -0002.
Qualification testing and approval for M15733/34-0010, -0019, and -0011, shall be sufficient to grant
qualification approval to M15733/34-0010, -0015, -0019, -0011, and -0013.
Qualification testing and approval for M15733/34-0023 and -0028 shall be sufficient to grant qualification
approval to M15733/34-0023, -0018, -0024, -0025, -0026, -0027, -0009, -0014, -0017, -0028, and -0035.
Initial qualification to MIL-PRF-15733/34 may be granted based on qualification to MIL-PRF-28861 or
MIL-PRF-15733/49 as indicated in table III. Extension of qualification from MIL-PRF-28861 or
MIL-PRF-15733/49 to MIL-PRF-15733/34 is permissible under the following provisions:
a. The MIL-PRF-15733/34 parts use the same design and dielectric characteristics as the part from which
qualification is extended.
