MIL-PRF-28861/1D
B
A
dimension
dimension
Dash
(±.010)
(max)
number
001
through
010
.357
.187
and
021
through
026
011
through
020
.482
and
.312
031
through
036
Inches
mm
Inches
mm
.003
0.08
.140
3.56
.005
0.13
.187
4.75
.007
0.18
.200
5.08
.010
0.25
.250
6.35
.015
0.38
.312
7.92
.022
0.56
.357
9.07
.045
1.14
.395
10.03
.070
1.78
.408
10.36
.093
2.36
.410
10.41
.115
2.92
.482
12.24
.120
3.05
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Circuit diagrams are for information only.
4. All filters shall be supplied with mounting hardware (hex nut and lockwasher). Mounting hardware
shall be furnished with the same finish as the filter case.
5. Terminal identification (nonsymmetrical filters): The case shall be marked at the threaded end of
the filter with the symbol "L" or the circuit diagram shall be marked on the case.
6. Optional slot may be supplied, .050 ±.010 inches (1.27 ±0.25 mm) x .070 ±.010 inches (1.78 ±0.25 mm).
7. Imperfect thread or undercut optional .050 inch (1.27 mm) maximum.
8. One imperfect thread allowed .035 inch (0.89 mm) maximum.
9. Recommended mounting torque: 44 inch-ounce ±4 inch-ounce.
FIGURE 1. Case and hardware dimensions and circuit diagrams - Continued.
2
