MIL-PRF-15733/49K
Filter
Hex nut
Lockwasher
dash
A
B
C
D
E
no.
Min
Max
Min
Max
Thread
Min
Max
Min
Max
0001
.302
3.22
.085
.095
.250-28
.396
.408
.017
.027
(7.67)
(8.18)
(2.16)
(2.41)
UNF-2B
(10.06)
(10.36)
(0.43)
(0.69)
0002
.307
.317
.088
.098
.250-28
.396
.408
.017
.027
(7.80)
(8.05)
(2.24)
(2.49)
UNF-2B
(10.06)
(10.36)
(0.43)
(0.69)
0003
.307
.317
.088
.098
.250-28
.396
.408
.017
.027
(7.80)
(8.05)
(2.24)
(2.49)
UNF-2B
(10.06)
(10.36)
(0.43)
(0.69)
0004
.307
.317
.088
.098
.250-28
.396
.408
.017
.027
(7.80)
(8.05)
(2.24)
(2.49)
UNF-2B
(10.06)
(10.36)
(0.43)
(0.69)
0005
.307
.317
.088
.098
.250-28
.396
.408
.017
.027
(7.80)
(8.05)
(2.24)
(2.49)
UNF-2B
(10.06)
(10.36)
(0.43)
(0.69)
0006
.302
.322
.085
.095
.250-28
.396
.408
.017
.027
(7.67)
(8.18)
(2.16)
(2.41)
UNF-2B
(10.06)
(10.36)
(0.43)
(0.69)
0007
.302
.322
.085
.095
.250-28
.396
.408
.017
.027
(7.67)
(8.18)
(2.16)
(2.41)
UNF-2B
(10.06)
(10.36)
(0.43)
(0.69)
0008
.307
.317
.088
.098
.250-28
.396
.408
.017
.027
(7.80)
(8.05)
(2.24)
(2.49)
UNF-2B
(10.06)
(10.36)
(0.43)
(0.69)
0010
.317
.098
.250-28
.396
.408
.017
.027
----
----
(8.05)
(2.49)
UNF-2B
(10.06)
(10.36)
(0.43)
(0.69)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Circuit diagrams are for information only.
4. All filters shall be supplied with mounting hardware.
5. Terminal identification. The case shall be marked at the threaded end of the filter, with the symbol "L" for
dash numbers 0001, 0003, 0004, 0006, and 0007.
6. Turret head is optional.
7. Flag terminals shall be aligned within 10 of the vertical (threaded bushing flats).
FIGURE 1. Case dimensions and circuit diagrams - Continued.
