MIL-PRF-15733/49K
Initial qualification to MIL-PRF-15733/49 may be granted based on qualification to MIL-PRF-28861/1 as indicated in
table II. Extension of qualification from MIL-PRF-28861/1 is permissible under the following provisions:
a. The MIL-PRF-15733/49 parts use the same design and dielectric characteristics as the comparable
MIL-PRF-28861/1 parts.
b. The MIL-PRF-28861/1 data verifies that the physical and electrical characteristics of the MIL-PRF-15733/49
parts are satisfied.
TABLE II. Extension of qualification.
Qualification to
Will qualify
Qualification to
Will qualify
MIL-PRF-15733/49
MIL-PRF-15733/49
MIL-PRF-15733/49
-001
-0003
-0006
-0001
-001
-0004
-0006
-0007
-001
-0006
-0006
-0008
-001
-0007
-001
-0008
-002
-0008
Supersession data: See table III.
TABLE III. Supersession data.
*
For new design use PIN
Inactive PIN
M83439/02-001
M15733/49-0008
M83439/02-003
M15733/49-0010
M15733/49-0001
M28861/01-001TB
M15733/49-0002
M28861/03-015TB
M15733/49-0003
M28861/01-001TB
M15733/49-0004
M28861/01-001TB
M15733/49-0005
M15733/38-0007
M15733/49-0006
M28861/01-001
M15733/49-0007
M28861/01-001TB
PIN M15733/49-0009 has been deleted. For new design, use M28861/01-010 of MIL-PRF-28861/1.
NOTES:
Cataloging information: Dash numbers 0008 and 0010 shall be cataloged under FSC 5910 as feed-through
ceramic capacitors. Dash numbers 0001 through 0007 shall be cataloged under FSC 5915 as radio frequency
interference filters.
Referenced documents: In addition to MIL-PRF-15733, this specification sheet references the following
*
documents:
8
