MIL-PRF-28861 Filters And Capacitors, Radio Frequency/Electromagnetic Interference Suppression, General Specification ForThis specification covers the general requirements for low-pass filter and capacitors used to suppress radio frequency/electromagnetic interference. Filters furnished to the requirements of this specification contain shunting ceramic discoidal capacitors and series inductors \(FSC 5915\). Capacitors furnished to the requirements of this specification contain shunting ceramic discoidal capacitors \(FSC 5910\). For the purposes of this specification, feed-through capacitor types \(C circuit configuration\) are referred to herein as a filter. Passband power may be alternating current \(ac\) or direct current \(dc\) and the filters used primarily in the reduction of broadband radio frequency interference. This specification provides for two levels of product assurance requirements. Filters covered by this specification are capable of operation over the temperature range of -55 degrees C to +125 degrees C.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13


. . . . . . . . . .
MIL-PRF-28861D
1.2.2 Style. The style (see 3.1) is identified by the two letter symbol "FS" followed by a two digit number. The
letters identify radio frequency/electromagnetic interference suppression filters and the two digits represent a voltage
rating, envelope size and configuration.
TABLE I. Case finish.
Symbol
Finish
T
tin-lead plated
S
Silver-plated
G
Gold-plated
TABLE II. Product assurance level.
Symbol
Level
S
Class S
B
Class B
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 or 4 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements of documents cited in sections 3 or 4 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation or contract.
FEDERAL STANDARDS
-
Screw-Thread Standards for Federal Services.
DEPARTMENT OF DEFENSE SPECIFICATIONS
-
Filters and Capacitors, Radio Frequency/Electromagnetic Interference
Suppression, Hermetically Sealed, Styles FS10 and FS11
-
Filters, Radio Frequency/Electromagnetic Interference Suppression, Hermetically
Sealed, Style FS20
-
Filters, Radio Frequency/Electromagnetic Interference Suppression, Hermetically
Sealed, Style FS30
-
Filters, Radio Frequency/Electromagnetic Interference Suppression, Hermetically
Sealed, Style FS40
-
Filters, Radio Frequency/Electromagnetic Interference Suppression, Hermetically
Sealed, Style FS50
-
Filters and Capacitors, Radio Frequency/Electromagnetic Interference
Suppression, Non-hermetically Sealed, Style FS60
Filters and Capacitors, Radio Frequency/Electromagnetic Interference
Suppression, Hermetically Sealed On One End Only, Style FS70
-
Capacitors, Fixed, Ceramic Dielectric, High Reliability, Discoidal, General
Specification For
2
