MIL-PRF-15733J
TABLE IV. Group A inspection.
Inspection
Requirement
Test
Sampling
paragraph
paragraph
procedure
Visual and mechanical inspection: 1/
See table V
Material
Body dimensions
Design and construction
(other than body dimensions)
inclusive
Marking
Workmanship
Seal
Capacitance to ground (when specified)
Dielectric withstanding voltage
Insulation resistance (terminal to ground)
DC voltage drop (when specified)
Insertion loss (25°C)
1/ Visual and mechanical examination may be performed before or after the units are sealed,
whichever is applicable.
TABLE V. Group A sampling plan.
Lot size
Sample size
2 to
13
100 percent
14 to
150
13
151 to
280
20
281 to
500
29
501 to 1,200
34
1,201 to 3,200
42
3,201 to 10,000
50
4.5.2 Periodic inspection. Periodic inspection shall consist of group C inspection. Except where the results of
these inspections show noncompliance with the applicable requirements (see 4.5.2.5), delivery of products which
have passed group A shall not be delayed pending the results of these periodic inspections.
4.5.2.1 Group C inspection. Group C inspection shall consist of the inspections specified in table VI, in the order
shown. Group C inspection shall be made on sample units selected from inspection lots that have passed group A
inspection.
4.5.2.2 Sampling plan.
4.5.2.2.1 Quarterly. Every 3 months, 10 sample units shall be subjected to the test of subgroup 4 of table VI and 5
sample units shall be subjected to the test of subgroup 5. Samples shall be selected according to style.
4.5.2.2.2 Semiannually. Every 6 months, 12 sample units (4 units for each subgroup) shall be subjected to the
tests of subgroups 1, 2, and 3 specified in table VI. Samples shall be selected according to style.
4.5.2.3 Defectives. If the number of defectives exceed the number allowed in table VI, the sample shall be
considered to have failed.
4.5.2.4 Disposition of sample units. Sample units that have been subjected to group C inspection shall not be
delivered on the contract.
10
