MIL-PRF-15733J
6.7.1.4 Terminal identification. Terminals are identified by a number and a letter in accordance with table XII. The
number identifies the type of material and the letter identifies the thread (or other dimensions).
TABLE XII. Terminal types and dimensions.
Symbol
Type of terminal
Thread or dimension
1E
Solder lug
---
2G
Radially tapped permanent stud
.164-32 UNC-2B
2H
Radially tapped permanent stud
.190-32 UNF-2B
3F
Threaded stud
.112-40 UNC-2A
3L
Threaded stud
.138-32 UNC-2A
3J
Threaded stud
.164-32 UNC-2A
3K
Threaded stud
.190-32 UNF-2A
3M
Threaded stud
.250-28 UNF-2A
3UN
Threaded stud
.3125-24 UNF-2A
3P
Threaded stud
.216-28 UNF-2A
6.7.1.5 Operating temperature range. The operating temperature range is identified by a single letter in
accordance with table XIII.
TABLE XIII. Operating temperature range.
Symbol
Temperature range
°C
A
-65 to +85, incl
B
-65 to +125, incl
C
-65 to +200, incl
D
-55 to +125, incl
E
-55 to +85, incl
W
(As specified)
6.7.1.6 Grade. The grade is identified by a single digit in accordance with table XIV.
TABLE XIV. Grade.
Symbol
Vibration condition
Hz
1
10 to 55, incl
2
10 to 500, incl
3
10 to 2,000 incl
6.8 Subject term (key word) listing.
EMI
Feed-through, filter
Insertion loss
Low pass, filter
RFI
6.9 Changes from previous issue. The margins of this specification are marked to indicate where changes from
the previous issue were made. This was done as a convenience only and the Government assumes no liability
whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate the
requirements of this document based on the entire content irrespective of the marginal notations and relationship to
the last previous issue.
22
